Ultralife U10025 3 Volt 4.8Ah "C" Cell LiMnO2 Lithium Battery

NOTE:
 This item is for 1 box of 3 batteries as packaged by Ultralife.
 The box price is $164.49 or $54.83 per battery

 The U10025 replaces the U2550HCES-F95 and is the only cell approved for use in the MIDS-LVT.
 All 3 cells MUST be replaced at the same time.

Technical Specifications
 Part No.: U10025
 NSN: 6135-01-545-6582
 Cell Size: C Size
 Voltage Range: 1.5 to 3.3 Volts
 Average Voltage: 3.0V
 Nominal Capacity: 4.8Ah @ 150mA to 2.0V @ 23°C
 Max. Discharge: 2.0A continuous
 Pulse Capability: Up to 2.6A Varies according to pulse characteristics, temperature cell history and the application. Consult Ultraife.
 PTC: PTC re-settable fuse
 Weight: 61.0g
 Terminals/Connector: Flat Ni-plated +/- End Caps

 Operating Temperature: -40°C to 72°C
 Storage Temperature: -55°C to 95°C (*)
 Exterior/Housing Hermetic: Ni-plated steel can. End caps, tabs and insulating sleeve

 Safety: Material Safety Datasheet - MSDS023
 Safety Guide UBM-5135
 Transportation: Class 9 - U.S. and International **
                          UN Testing Summary - UNTS-0052
 Export License: ECCN 3A611.x. export license required to export from U.S.
 Harmonized Tariff Schedule: 8506.50.0000

Notes
 *   Storage at elevated temperatures for long periods of time reduces operational life and is not recommended. Storage at +95°C up to 4 hour
      periods is achievable.
 ** A complete description of transportation regulations, lithium weights and transportation classifications is available on the Ultralife website.
